| Gantry Crane Suspended Turning Device

Efficient Lifting and Turning Device Designed for Heavy Workpieces

The gantry crane suspended turning device is an automated lifting solution installed beneath gantry crane, designed to achieve workpiece lifting, turning and precise positioning. Operating together with the gantry crane system, the device can perform 0° - 360° rotation of large steel structures, mechanical components, molds, metal plates, castings and welded assemblies, significantly improving material handling efficiency and operational safety on production lines.

Compared with traditional manual turning or standard lifting methods, the suspended turning device effectively reduces the risk of workpiece damage, minimizes manual intervention, improves turning synchronization and positioning accuracy.

High Strength Structural Design Ensures Stable and Safe Turning Performance

The crane suspended turning device is welded with high strength steel structure, and the overall structure is verified through finite element stress analysis and dynamic load checking, ensuring excellent stability even under heavy duty continuous operation.

• High strength load-bearing main beam

• Dual-side synchronized turning drive system

• Heavy duty chain or gear transmission mechanism

• Safety mechanical limit devices

• Electrical synchronous control system

Performance Features of the Crane Suspended Turning Device

• Designed with high strength steel structure to provide stable load-bearing performance for lifting and turning loads from 0.5 ton to 10 tons.

• Supports precise positioning at any angle to meet multi-station production requirements such as welding, assembly, coating and maintenance.

• Equipped with synchronized drive control system to ensure balanced force distribution on both sides during the turning process, effectively preventing load shifting, swinging or tilting.

• Integrated with multiple safety protection systems, including overload protection, mechanical limit devices, anti-drop locking mechanisms, emergency stop functions and anti-tilt control systems.

• Supports customized design according to load capacity, workpiece dimensions, turning angles, lifting space and automation requirements.

Widely Used in Heavy Manufacturing and Automated Production Industries

Steel Structure Manufacturing: Used for turning and welding H-beams, box girders and bridge structural components.

Wind Power and New Energy Industry: Suitable for rotating tower sections, turbine components, wind turbine blades and large-scale energy equipment.

Shipbuilding and Offshore Engineering: Provides safe lifting and turning for large plates and hull section structures.

Automotive Manufacturing: Used for turning vehicle body structural parts and chassis components.

Frequently Asked Questions

Q: What is the difference between suspended turning device and standard lifting beam?

A: Standard lifting devices are only used for lifting and transporting loads, while suspended turning devices can also rotate and precisely position workpieces, greatly improving welding, assembly and automated production efficiency.

Q: Can the turning device be used with overhead crane?

A: Yes. The turning device can be adapted to existing overhead crane according to lifting capacity, span and operating mode without requiring major modifications to the existing equipment.

Q: How to select the right suspended turning device?

A: Key factors to consider include workpiece weight and dimensions, required turning angle, belt or chain slings, turning frequency, working environment and safety level requirements.

Q: What are the advantages of the crane suspended turning device?

A: Improved production efficiency, reduced labor costs, enhanced turning accuracy, less workpiece damage and higher operational safety.

If you are looking for high quality crane suspended turning device with customized design support, KUNFENG can provide professional technical support and complete industrial material turning solutions. Click here to contact us for more product details and quotations.
